Furuno DFF1-UHD CHIRP Fish Finder Module
$900.00
Furuno DFF1-UHD CHIRP Fish Finder Module adds 1 kW broadband CHIRP sonar, Accu-Fish, and bottom discrimination to compatible Furuno NavNet displays.
Description
Overview Furuno DFF1-UHD CHIRP Fish Finder Module
Furuno DFF1-UHD CHIRP Fish Finder Module is a black-box 1 kW sonar module built for compatible Furuno NavNet 3D and TZtouch display systems. It uses TruEcho CHIRP processing to deliver better fish separation and more detailed bottom information than a basic single-frequency sounder.
The module is intended for boats that already rely on Furuno multifunction displays but want stronger dedicated fishfinding capability. Its black-box design keeps the helm clean while pushing sonar processing into a protected equipment space.
Key Features
- 1 kW CHIRP sonar module: Provides dedicated fishfinding power to compatible Furuno display systems.
- Broadband frequency sweep: The source description states a 90-frequency sweep around 50 kHz and 200 kHz ranges.
- Accu-Fish and bottom discrimination: Adds analysis tools that help interpret fish size and seabed composition.
- Designed for NavNet integration: Built to work with compatible NavNet 3D and TZtouch multifunction displays.
- Remote black-box format: Useful when space at the console is limited but network sonar is still required.
Applications
Well suited to offshore and coastal fishing boats that already run Furuno multifunction displays and want a cleaner, more capable network fishfinder at the helm.
Specifications
| Technology | TruEcho CHIRP (broadband) |
| Output Power | 1 kW |
| Frequencies | 50 kHz ± 20 kHz / 200 kHz ± 25 kHz (90 frequencies) |
| Advanced Features | Bottom discrimination, Accu-Fish |
| Compatibility | NavNet 3D / TZtouch MFD systems |
| Interface | Ethernet network connection |
| Waterproof Rating | IP22 module |
| Power Requirements | 12 – 24 VDC |
What’s Included
- Furuno DFF1-UHD TruEcho CHIRP Black Box Sonar Module
- LAN Cable (5 Meters)
- Power Cable Assembly
- Installation Hardware Kit
- Comprehensive Installation and Operation Documentation
Reviews (0)
FAQ
Frequently Asked Questions About Furuno DFF1-UHD CHIRP Fish Finder Module
What is Furuno DFF1-UHD CHIRP Fish Finder Module designed for?
Furuno DFF1-UHD CHIRP Fish Finder Module is a black-box 1 kW sonar module built for compatible Furuno NavNet 3D and TZtouch display systems. It uses TruEcho CHIRP processing to deliver better fish separation and more detailed bottom information than a basic single-frequency sounder.
What sonar capabilities does it provide?
Key source details include 1 kW CHIRP sonar module, Broadband frequency sweep, and Accu-Fish and bottom discrimination. Together with Ethernet network connection and 50 kHz ± 20 kHz / 200 kHz ± 25 kHz (90 frequencies), these features support deeper-water sounder work and detailed underwater interpretation.
Is this sonar system suited to onboard marine use?
Yes. The product information lists IP22 module, supporting marine installation in working conditions. The module is intended for boats that already rely on Furuno multifunction displays but want stronger dedicated fishfinding capability. Its black-box design keeps the helm clean while pushing sonar processing into a protected equipment space.
What system support or integration options does it offer?
The source data lists Ethernet network connection for system support or integration. The module is intended for boats that already rely on Furuno multifunction displays but want stronger dedicated fishfinding capability. Its black-box design keeps the helm clean while pushing sonar processing into a protected equipment space.
